停產通知

停產原因: 1. Intel has announced the end-of-life (EOL) of the Intel® Core™ i5-1240P and i7-1260P processors in Change Notification #839177-00. As a result, the UP Squared i12 and UP Xtreme i12 P/Ns that utilize these processors—UPS-ADLP and UPX-ADLP—will be discontinued. (Phaseout effective date: 2025/06/30. Last-buy date: 2026/01/30) 2. Intel has announced the end-of-life (EOL) of the Intel® Core™ i5-1340P and i7-1360P processors. As a result, the UP Squared i12/Edge and UP Xtreme i12/Edge P/Ns that utilize these processors—UPS-RAP and UPX-RAP—will be discontinued.
生效日期: 2026-03-03
最後購買日期: 2026-09-11
推薦: 1. UPS-RAPI5-A10-0800, UPS-RAPI7-A10-0800, UPS-RAPI7C-A10-1600 2. UPS-RAPI5-A10-0800, UPS-RAPI7-A10-0800

check_box_outline_blank Compare

UP Squared i12 | Alder Lake P developer board

UP Squared i12 －適用於邊緣運算的精巧 Intel® Core™ 單板電腦

Name: UP Squared i12｜Intel Core i7/i5/i3/Celeron 單板電腦
Brand: AAEON Technology Inc

UP Squared i12 (UPS-ADLP/UPS-RAP) 是搭載 12/13 代 Intel® Core™/Celeron® 7000 系列處理器（代號 Alder Lake P/Raptor Lake）最小的主機板，尺寸僅有 85.6mm × 90mm，大小與 PICO 相當。此外，專為工業應用開發者設計的 UP Squared i12 配備了與樹莓派兼容的 40-pin 排針，具有更多開發平台的優勢。

彈性擴充與儲存配置選項

UP Squared i12 包含了高速界面與高達 16GB 的板載 LPDDR5 記憶體，並配有兩個 MIPI-CSI 相機連接埠、兩個顯示輸出、GbE LAN 以及 USB埠，與樹莓派兼容的 40-pin 排針提供了額外擴充功能，同時也支援 AI 加速模組和 Wi-Fi 模組的擴充插槽，可外接 SSD、NVMe 和 SATA III。
